FLEEX rigid interface for concrete slab
FLEEX rigid interface for concrete slab
Warranty 5 years
Standard: EN 795:2012/CENTS-16415
Select your reference
FLEEX rigid interface for concrete slab
Technical characteristics
| Concrete fastening kit - 4 studs | |
|---|---|
| Reference : | F-P-201A |
| Quantity : |
|
| (7.7) 450 mm galvanised steel pole | |
|---|---|
| Reference : | EEHL58434 |
| Quantity : |
|
| Intermediate 1 deflection item | |
|---|---|
| Reference : | EEHL201 |
| Quantity : |
|
| Pulley for the corner passage on the post | |
|---|---|
| Reference : | EEHL745 |
| Quantity : |
|
| Stainless steel end anchor for the EEHL58434 pole | |
|---|---|
| Reference : | EEHL734-722.51 |
| Quantity : |
|
Use
Rigid post for concrete slab to be combined with the FLEEX starting kits.
Used:
- at the lifeline end (with the EEHL58434 anchor)
- in intermediate passage (with the EEHL201 part)
- in the lifeline angle (with the EEHL745 pulley)
Maximum reach : 10 m (33')
Technical description
Galvanised steel post and flange
Post height: 450 mm (18")
Post cross section : 80 x 80 mm (3" x 3")
Post supplied with flange
Maximum lifeline angle: 90°
Documentation
-
![]()
